Holley 600 CFM Supercharger Double Pumper Carburetor-Draw Thru Design 0-80592S

Holley 600 CFM Supercharger Double Pumper Carburetor-Draw Thru Design 0-80592S
Holley 600 CFM Supercharger Double Pumper Carburetor-Draw Thru Design 0-80592SHolley 600 CFM Supercharger Double Pumper Carburetor-Draw Thru Design 0-80592SHolley 600 CFM Supercharger Double Pumper Carburetor-Draw Thru Design 0-80592SHolley 600 CFM Supercharger Double Pumper Carburetor-Draw Thru Design 0-80592SHolley 600 CFM Supercharger Double Pumper Carburetor-Draw Thru Design 0-80592SHolley 600 CFM Supercharger Double Pumper Carburetor-Draw Thru Design 0-80592S
$1,464.99 ea
NEW
Model: 3990477
STANDARD
DELIVERY
Holley Double Pumper® carburetors are a perfect performance upgrade for hot street cars and race vehicles. Double Pumper carburetors are an American icon when it comes to performance carburetors. From their roots as the premier carburetor on many factory muscle cars to powering thousands of vehicles across the finish line, the Double Pumper is a great choice whether you are burning up the street or the quarter mile. The Double Pumper is designed for use on lightweight vehicles with a manual transmission or an automatic transmission with a high stall and low rear end gears. The Supercharger Double Pumper with a tumble polished shiny finish and features dual accelerator pumps for additional fuel under initial acceleration; mechanical secondaries for great performance; dual feed fuel inlets for constant high volume fuel delivery and a manual choke for easy control of engine warm up. These carburetors that are intended for use with superchargers, and have a unique capability that allows their power valves to reference the intake manifold vacuum below the supercharger. This allows the power valve to operate as it should, based off intake manifold vacuum. A power valve provides further enrichment to the main metering system under load (low vacuum) conditions. Without this external referencing, the power valve would be "reading" the supercharger vacuum, which has no bearing on the engine load.
Features:
  • Tumble polished shiny finish for good looks
  • Chevrolet small block 2 x 4, 671 blower calibration
  • Manual (Cable driven, hand operated) choke for precise cold start control
  • Dual 50cc accelerator pumps for addition fuel under initial acceleration
  • Dual feed fuel inlets for constant high volume fuel delivery
  • Mechanical Secondaries for perfect off the line launches
  • 2 corner idle allows you to precisely control your idle system
  • Intended for lightweight vehicles w/ manual trans or automatics with high stall & low gearing
  • Boost referenced power valve for proper enrichment under acceleration
  • Throttle lever cut off for clearance on a sideways application
  • 100% wet-flow tested by Holley technicians to assure it arrives ready to run!
This model of carburetor has the square bore flange bolt pattern. It can replace Holley, Edelbrock, Carter AFB, and Autolite style carburetors with 5 3/16" x 5 5/8" bolt pattern. If you have a spreadbore style intake manifold, you will need an adapter to install this carburetor. Similar to the Mr. Gasket #1932.
Installation Notes:
This model of carburetor has the square bore flange bolt pattern. It can replace Holley, Edelbrock, Carter AFB, and Autolite style carburetors with 5 3/16" x 5 5/8" bolt pattern. If you have a spreadbore style intake manifold, you will need an adapter to install this carburetor. Similar to the Mr. Gasket #1932.

About Holley Performance Products

Holley has been the undisputed leader in fuel systems for over 100 years. Holley carburetors powered every Monster Energy NASCAR Cup team and nearly every NHRA Pro-Stock champion for four decades. Now, Holley EFI products power these cars and are dominating the performance world. Holley products for GM's popular LS engine are dominating the LS scene as well. Holley's products also include performance fuel pumps, intake manifolds and engine dress-up products for street performance, race and marine applications. As a single solution or partnered with products from other Holley companies we can give you the edge you need over the competition!

Downloads:

Download Name File Size
techlibrary_carb_numerical_listing.pdf611.91KB
199r10171.pdf77.19KB

Videos:

Specifications:

Barrels 4
Booster Straight
Booster Type Straight
Carburetor Use Performance and Race
CFM 600
Choke Manual
Condition NEW
Emission Code 3
Finish Shiny
Fuel Gasoline
Fuel Inlet Dual
Marine Use No
Material Aluminum
Model 4150
Part Type Carburetor
Primary Main Jet 68
Primary Power Valve 6.5
Product Type Carburetor
Proposition 65 www.P65Warnings.ca.gov
Secondaries Mechanical
Secondary Main Jet 76
Secondary Power Valve N/A
Supercharged Application Yes
System Type Draw Thru
Throttle Bore 1.563 inch
Warranty Limited 90 Day
