For over 26 years, Aeromotive has been committed to designing and manufacturing the highest quality fuel systems and components for OE applications and the automotive aftermarket. A brand backed by integrity and reliability, a passion for performance and a hands-on, real world approach drove Aeromotive to its position as industry leader. Since our previous acquisition in 2015, PerTronix has been searching for a strong automotive brand in its growth cycle with a strong culture that would align well with PerTronix Performance Brands and 2020 brought with it the acquisition of Aeromotive and Waterman Racing Components. Moving forward, our teams will foster collaboration on new product development, processes and best practices with each brand operating from their existing locations to benefit from the capabilities of their respective manufacturing facilities.
| Download Name | File Size |
| 183-2710-0.pdf | 958.97KB |
| Make | Model | Submodel | Years | Engine |
| Chevrolet | Chevy II | Nova | 1962 | 3.2L / 194 / L6 2.5L / 153 / L4 |
| Chevrolet | Chevy II | Nova | 1963 | 4.6L / 283 / V8 3.2L / 194 / L6 2.5L / 153 / L4 |
| Chevrolet | Chevy II | Nova | 1964 | 3.8L / 230 / L6 4.6L / 283 / V8 3.2L / 194 / L6 2.5L / 153 / L4 |
| Chevrolet | Chevy II | Nova | 1965 | 3.8L / 230 / L6 4.6L / 283 / V8 3.2L / 194 / L6 5.3L / 327 / V8 2.5L / 153 / L4 |
| Chevrolet | Chevy II | 1962 | 3.2L / 194 / L6 2.5L / 153 / L4 |
|
| Chevrolet | Chevy II | 1963 | 4.6L / 283 / V8 3.2L / 194 / L6 2.5L / 153 / L4 |
|
| Chevrolet | Chevy II | 1964 | 3.2L / 194 / L6 4.6L / 283 / V8 3.8L / 230 / L6 2.5L / 153 / L4 |
|
| Chevrolet | Chevy II | 1965 | 3.2L / 194 / L6 4.6L / 283 / V8 3.8L / 230 / L6 5.4L / 327 / V8 5.3L / 327 / V8 2.5L / 153 / L4 |
| Attached Sump | No |
| Baffled | Yes |
| Capacity | 16 GAL |
| Color | Silver |
| Filler Neck Attached | Yes |
| Finish | Powder Coated |
| Fuel Cap Included | No |
| Fuel Pump Included | Yes |
| Fuel System Compatibility | Carburation & Fuel Injection |
| Fuel Type | Gas |
| Grade Type | Performance |
| Height | 27 IN |
| Integrated Controller | No |
| Length | 47 IN |
| Lock Ring Included | Yes |
| Material | Steel |
| Maximum Current Draw | 13A @ 40PSI |
| Maximum Flow Rating | 340LPH |
| Maximum Pressure | 105PSI |
| Motor Style | Brushed |
| Mounting Hardware Included | No |
| Mounting Straps Included | No |
| Negative Ground | Yes |
| O Ring Included | Yes |
| Outlet Outside Diameter | ORB-06 |
| Outlet Type | Female |
| Part Type | Fuel Tank |
| Pressure Range | 3-65 |
| Prop 65 Flag | Yes |
| Pulse Width Modulation Compatible | Yes |
| Pump Design | Turbine Impeller |
| Return Fitting Size | ORB-06 |
| Sender Ohm Range | 0-30 |
| Sending Unit Included | Yes |
| Series | Stealth |
| Terminal Gender | Male |
| Terminal Quantity | 3 |
| Terminal Type | Threaded Stud |
| Universal Or Specific Fit | Specific |
| Voltage | 12-16V |
| Warranty Time | 12 Months |
| Width | 10 IN |
